Description

TP-Link TL-SG3428MP JetStream 28-Port Gigabit L2 Managed Switch with 24-Port PoE+


384 W PoE Budget: 24× 802.3at/af-compliant PoE+ ports with a total power supply of 384 W*.

Full Gigabit Ports: 24× gigabit PoE+ ports and 4× gigabit SFP Slots provide high-speed connections.

Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralised Cloud Management, and Intelligent Monitoring.

Centralised Management: Cloud access and Omada app for ultra convenience and easy management.

Static Routing: Helps route internal traffic for more efficient use of network resources.

Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.

Optimise Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.

Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities


HARDWARE FEATURES

Interface 24× 10/100/1000Mbps RJ45 Ports

4× Gigabit SFP Slots

1× RJ45 Console Port

1× Micro-USB Console Port

Fan Quantity 2

Power Supply 100-240 V AC~50/60 Hz

PoE+ Ports(RJ45) Standard: 802.3at/af compliant

PoE+ Ports: 24 Ports, up to 30 W per port

Power Budget: 384 W

Dimensions ( W x D x H ) 17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm)

Mounting Rack Mountable

Max Power Consumption 31.0 W (110 V/60 Hz) (no PD connected)

463.8 W (110 V/60 Hz) (with 384 W PD connected)

Max Heat Dissipation 105.78 BTU/h (110 V/60 Hz) (no PD connected)

1582.49 BTU/h (110 V/60 Hz) (with 384 W PD connected)


PERFORMANCE

Switching Capacity 56 Gbps

Packet Forwarding Rate 41.66 Mpps

MAC Address Table 8K

Jumbo Frame 9 KB

Specifications
SKU NWTL-SG3428MP
Barcode # 6935364010737
Brand TP-LINK
Shipping weight 6.7000kg
Shipping width 0.202m
Shipping height 0.540m
Shipping length 0.632m
Assembled length 5.320m
Assembled height 4.400m
Assembled width 1.020m

TP-Link TL-SG3428MP JetStream 28-Port Gigabit L2 Managed Switch with 24-Port PoE Static RoutingOmada

$649.60
RRP $799.00 save 19%

or 4 payments of $162.40 with Learn more

Sold Out

Product Information

SKU:

NWTL-SG3428MP

Brand:

TP-LINK

Barcode #:

6935364010737

Shipping Weigth:

6.7000kg

Warranty:

60
