POSTAGE

Description

Gigabyte P750BS Power Supply, 750W, ATX12V, 80 PLUS Bronze Fan, Type 120mm Fluid Dynamic Bearing fan 100,000 hours, 3 years warranty


Model GP-P750BS

Type Intel Form Factor ATX 12V

PFC Active PFC (0.9 typical)

Input Voltage 200-240 Vac

Input Current 6A

Input Frequency 60-50 Hz

Output Capacity 750W

Dimension 150 x 140 x 86 mm

Fan Type 120mm Fluid Dynamic Bearing (FDB) Fan

80 Bronze (230V EU)

Efficiency 88pct at typical load

MTBF 100,000 hours

Protection OVP OPP SCP UVP OCP OTP

Power Good Signal 100-150ms

Hold Up Time 16ms

Cable Type Embossed, All black

Connectors

ATX MB 204 Pin x 1 : 600mm1

CPU EPS 44 Pin x 2 : 600mm150mm1

PCI-E 62 Pin x 4 : 500mm150mm2

SATA x 4 : 500mm150mm150mm150mm1

SATA x 3 Peripheral x1 : 500mm150mm150mm150mm1

Specifications
SKU PSG-P750BS
Barcode # 4719331555269
Brand Gigabyte
Shipping weight 2.7200kg
Shipping width 0.314m
Shipping height 0.218m
Shipping length 0.356m

Gigabyte P750BS Power Supply, 750W, ATX12V, 80 PLUS Bronze Fan, Type 120mm Fluid Dynamic Bearing fan

$219.58

or 4 payments of $54.90 with Learn more

In Stock

Product Information

SKU:

PSG-P750BS

Brand:

Gigabyte

Barcode #:

4719331555269

Shipping Weigth:

2.7200kg
