Output

Output power capacity: 390 Watts 620 VA

Max Configurable Power (Watts): 390 Watts 620 VA

Nominal Output Voltage: 230V

Output Voltage Distortion: Less than 5pct at full load

Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal

Topology: Line Interactive

Waveform type: Stepped approximation to a sinewave

Output Connections:

(1) IEC 320 C13 (selector_surgetitle)

(3) IEC 320 C13 (Battery Backup)

Transfer Time: 2ms typical

Input

Nominal Input Voltage: 230V

Input frequency: 50 60 Hz - 3 Hz (auto sensing)

Input Connections: IEC-320-C14 inlet

Input voltage range for main operations: 195 - 265 V

Batteries Runtime

Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof

Typical recharge time: 5.5 hour(s)

Replacement Battery: RBC4

RBC Quantity: 1

Battery Volt-Amp-Hour Capacity: 132

Runtime: View Runtime Graph View Runtime Chart

Efficiency: View Efficiency Graph

Communications Management

Interface Port(s): DB-9 RS-232

Control panel: LED status display with On Line: On Battery: Replace Battery and Overload indicators

Audible Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm

Emergency Power Off (EPO): N A

Surge Protection and Filtering

Surge energy rating: 320 Joules

Data Line Protection: RJ-45 Modem Fax DSL 10-100 Base-T protection

Filtering: Full time multi-pole noise filtering: 0.7pct IEEE surge let-through: zero clamping response time: meets UL 1449

Physical

Maximum Height: 168, 16.8 cm

Maximum Width: 119, 11.9 cm

Maximum Depth: 375, 37.5 cm

Net Weight: 12.27 kg

Shipping weight: 13.18 kg

Shipping Height: 318, 31.8 cm

Shipping Width: 262, 26.2 cm

Shipping Depth: 508, 50.8 cm

Color: Grey

Environmental

Operating Environment: 0 - 40 degreeC

Operating Relative Humidity: 0 - 95 pct

Operating Elevation: 0-3000 meters
