Description

The DS20U-series is a fanless slim PC with a robust 1.3-litre metal chassis and exceptional connectivity. It supports two digital video outputs for UHD/4K displays and one tradi-tional D-Sub/VGA connector. The built-in Intel 'Comet-Lake-U' processor provides ample performance for playback of 2160p/60 videos. Installation of components goes straight forward, as there is plenty of interior space for two memory modules, one 2.5' drive and an M.2-2280 SSD card. Optionally, an LTE module can be fitted in the 2,5' bay using the WWN03 accessory. Thanks to its passive cooling, the system is virtually maintenance-free and is approved for 24/7 nonstop operation. It is big on performance, yet extremely energy-efficient. The Shuttle XPC slim Barebone DS20U series is an ideal platform for professional applications such as digital signage, POS, Kiosk, Thin Client, Office PC and Multimedia.


Intel Celeron 5205U (1,9 GHz, 2 cores, 2 threads, 2 MB cache)

Intel UHD Graphics

Up to 64 GB of DDR4 memory

1× NVMe, 1× SATA 2.5', card reader

1× HDMI 2.0b, 1× DisplayPort 1.2, 1× VGA

Two M.2 slots (1× M.2-2280, 1× M.2-2230)

2× Gigabit Ethernet, WLAN-ready, 4G-ready

4× USB 3.2 Gen 1 (5 Gbit), 4× USB 2.0, 1× COM

Remote power-on connector, always-on jumper

Wall/VESA mount included

Optional DIN-Rail/19' mount

Specifications
SKU SYS-DS20U3
Barcode # 887993003917
Brand Shuttle
Shipping weight 2.6000kg
Shipping width 0.320m
Shipping height 0.120m
Shipping length 0.120m
Assembled length 0.200m
Assembled height 0.200m
Assembled width 2.200m

Shuttle DS20U3 Slim Mini PC 1L Barebone- Intel Core i3-10110U Fan-less 2x LAN RS232 RS422 RS485 HDMI DP VGA Vesa Mount 65W adapter

$1,089.24
RRP $1,291.00 save 16%

or 4 payments of $272.31 with Learn more

Only 1 Left!

Product Information

SKU:

SYS-DS20U3

Brand:

Shuttle

Barcode #:

887993003917

Shipping Weigth:

2.6000kg
