Description

Local and Remote Units connect at distances up to 300 m using Cat 5e cable

Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles

Deskew Function - automatically synchronizes the time delay of RGB signals to compensate for distance

Built-in ASIC for greater reliability and compatibility

Auto Signal Compensation (ASC)

RS-232 serial ports - allow you to connect to a serial terminal, or serial devices such as touchscreens and barcode scanners

Sun/Mac keyboard support and emulation*

Audio Enabled - supports stereo speakers and microphone

USB overcurrent detection and prevention

Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes, with the press of a single button

Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection

High resolution video - up to 1920 x 1200@60Hz (150 m); 1280 x 1024@60Hz (300 m)

Superior Audio - no loss in audio quality at 300 m

Spports Wide Screen formats

Supports VGA, SVGA, SXGA (1280 x 1024), UXGA (1600 x 1200), WUXGA (1920 x 1200) and multisync monitors; local monitor supports DDC; DDC2; DDC2B

Hot pluggable

Rack mountable

Easy to install - no software required - connecting cables to the devices is all it takes


*1. PC keyboard combinations emulate Sun/Mac keyboards

*2. Sun/Mac keyboards only work with their own computers


Compatible Cables: 2L-5301U, 2L-5302U, 2L-5303U, 2L-5304U, 2L-5305U, 2A-130G

Specifications
SKU KVA-CE-770
Barcode # 4710423776432
Brand Aten
Shipping weight 2.4400kg
Shipping width 0.200m
Shipping height 0.312m
Shipping length 0.426m
Assembled length 3.260m
Assembled height 2.120m
Assembled width 1.000m

Aten KVM Extender Kit VGA Audio Cat 5 Extender With Deskew 1920x1200 60Hz 150m 1280x1024 60Hz 300m

$596.24
RRP $669.00 save 11%

or 4 payments of $149.06 with Learn more

Sold Out

Product Information

SKU:

KVA-CE-770

Brand:

Aten

Barcode #:

4710423776432

Shipping Weigth:

2.4400kg

Warranty:

12
