MSI MPG Z890I EDGE TI WIFI, INTEL Z890, 2x DDR5 128GB, 1x HDMI, 1x PCI-E x16 slot, 4x M.2, 2x SATA, 2x USB 2.0, 2x USB C, Intel Killer BE1750x Wi-Fi
Chipset INTEL Z890
CPU Supports Intel Core Ultra Processors (Series 2) LGA 1851
Memory
2x DDR5, Maximum Memory Capacity 128GB
Memory Support 8600 - 6400 (OC) MT s 6400 - 4800 (JEDEC) MT s
Max. overclocking frequency:
1DPC 1R Max speed up to 8600 MT s
1DPC 2R Max speed up to 7200 MT s
Supports Intel POR Speed and JEDEC Speed
Supports Memory Overclocking and Intel XMP 3.0
Supports Dual-Controller Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM
Onboard Graphics
1x HDMI
Supports HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz
2x Type-C DisplayPort
ThundeboltTM 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K 120Hz 8K 60Hz
Slot
1x PCI-E x16 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E1 support manual BIOS adjustment to X8X8 X8X4X4
Storage
4x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 SATA mode, supports 2280 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280 devices
2x SATA 6G
USB
2x USB 2.0 (Front)
2x USB 5Gbps Type A (Front)
7x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Rear)
1x USB 20Gbps Type C (Front)
LAN 1x Intel Killer E5000B 5G LAN
WIRELESS LAN BLUETOOTH Intel Killer BE1750x Wi-Fi 7
OPERATING SYSTEM Support for Windows 11 64-bit
PCB Info Mini-ITX
170mmx170mm
| SKU | MBM-Z890IEDGETIWIFI |
| Barcode # | 4711377274494 |
| Brand | MSI |
| Shipping weight | 1.3400kg |
| Shipping width | 0.162m |
| Shipping height | 0.320m |
| Shipping length | 0.372m |
