The worlds first security camera system designed for interior design professionals.
Features:
8 MP wide angle lens 97.5˚(H) for wall mounted application (included)
12 MP fisheye 360° lens for ceiling mounted applications (included)
Two-way audio (UVC-AI-Theta-Audio sold separately)
Advanced AI processing engine for long-range smart detections
Color LCM display for device status monitoring
Managed with the UniFi Protect application: Version 2.7.18 and later (web) / 1.11.0 and later (mobile)
Mechanical
Dimensions UVC-AI-Theta-Hub: 140 x 70 x 38 mm (5.5 x 2.8 x 1.5')
UVC-AI-Theta-Lens/360: Ø22.8. x 43.5 mm (Ø0.9 x 1.7')
Weight UVC-AI-Theta-Hub: 330 g (11.6 oz)
UVC-AI-Theta-Hub Mount: 35 g (1.2 oz)
UVC-AI-Theta-Lens/360: 15 g (0.5 oz)
UVC-AI-Theta-Lens/360 Flush Mount: 12 g (0.4 oz)
Enclosure materials UVC-AI-Theta-Hub: aluminum alloy
UVC-AI-Theta-Lens/360: aluminum alloy, polycarbonate
UVC-AI-Theta-Lens/360 Flush Mount: polycarbonate
Mount materials UVC-AI-Theta-Hub: aluminum alloy
UVC-AI-Theta-Lens/360: aluminum alloy, polycarbonate
UVC-AI-Theta-Lens/360 Flush Mount: polycarbonate
Cable jacket enclosure dimensions 28 x 13 x 7.5 mm (1.1 x 0.5 x 0.3')
Cable jacket enclosure material PVC
Cable length 1 m (3.3 ft)
Cable diameter 3.7 mm (0.15')
Cable jacket material Woven fabric
Cable weight 18 g (0.63 oz)
Cable connector type Theta proprietary
Optics
Sensor UVC-AI-Theta-Lens: 8MP CMOS sensor
UVC-AI-Theta-Lens-360: 12MP CMOS sensor
Lens Fixed focal length
View angle UVC-AI-Theta-Lens: H: 97.5°, V: 79.4°, D: 118.2°
UVC-AI-Theta-Lens-360: H: 180°, V: 180°, D: 180°
Video
Video compression H.264, MJPEG
Resolution UVC-AI-Theta-Lens: 3264 x 2448 (4:3)
UVC-AI-Theta-Lens-360: 2560 x 2560 (1:1)
Max. frame rate UVC-AI-Theta-Lens: 24 FPS
UVC-AI-Theta-Lens-360: 20 FPS
Image settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
SKU | NHU-UVC-AI-THETA |
Barcode # | 810010079701 |
Brand | Ubiquiti |
Shipping weight | 1.3000kg |
Shipping width | 0.238m |
Shipping height | 0.156m |
Shipping length | 0.304m |
Assembled length | 2.040m |
Assembled height | 0.560m |
Assembled width | 1.380m |
Ubiquiti Camera UVC-AI-THETA 8MP Wide Angle Lens (97.5 H) 12MP Fisheye 360 Lens Colour LCM Display For Device Status Monitoring
