Gigabyte Radeon RX 9070 XT GAMING OC ICE 16G, GDDR6, 3060MHz boost, 2520MHz, 4096 cores, PCIe 5.0, 288mm, 850W, 2x DP 2.1a, 2x HDMI 2.1b

SPECIFICATION

Graphics Processing Radeon„ RX 9070 XT

Core Clock Boost Clock : up to 3060 MHz (Reference card: 2970 MHz)

Game Clock : up to 2520 MHz (Reference card: 2400 MHz)

Stream Processors 4096

Memory Clock 20 Gbps

Memory Size 16GB

Memory Type GDDR6

Memory Bus 256 bit

Card Bus PCI-E 5.0

Digital max resolution 7680x4320

Multi-view 4

Card size L=288 W=132 H=56 mm

PCB Form ATX

DirectX DirectX 12 API

OpenGL 4.6

Recommended PSU 850W

Power Connectors 8 pin3

Output DisplayPort 2.1a 2

HDMI 2.1b 2

Accessories Quick guide

Note

œBoost Clock ft is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. GD-151

œGame Clock ft is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. GD-147
