GIGABYTE Gen4 4000E SSD 1TB, PCI Express 4.0x4, M.2, 1000GB, Up to 4000 MB s, 3900 MB s, MTBF 1.5M hours, 3 y Warranty

Specification

Interface PCI Express 4.0x4, NVMe 1.4

Form Factor M.2 2280

Total Capacity 1000GB

External DDR Cache N A

Sequential Read speed Up to 4000 MB s

Sequential Write speed Up to 3900 MB s

Dimension 22 x 2.3 x 80 mm

Mean time between failure (MTBF) 1.5M hours

Max. Operating Power Read: 4400mW Write:4000mW

Power Consumption (Idle, PS3) 50mW

Power Consumption(PS4, L1.2) 5mW

Temperature (Operating) 0 degreeC to 70 degreeC

Temperature (Storage) -40 degreeC to 85 degreeC

Warranty

1. Limited 3 years or 320TBW.

2. Limited warranty based on 3 years or 320TBW, whichever comes first. (TBW is evaluated by JEDEC workload standard. )

TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.

3. When the usage of an NVME SSD as indicated by the ft ftPercentage Used ft ft (SMART ID: 05) in SMART page of ft ftGIGABYTE SSD toolbox ft ft reaches 100 means out of warranty. (A new unused product will show the number of 0)

Note

Test system configuration: configuration may vary by models, we will choose the latest platform for verification.

Performance may vary based on SSD fts firmware version and system hardware configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.

Speeds based on internal testing. Actual performance may vary.

1GB = 1 billion bytes. Actual useable capacity may vary.
