PANEL Screen Size 86'(85.6')

Panel Technology TFT LCD

Display Resolution 3840x2160

Brightness (Type) 350cd/㎡

Contrast (Type) 1200:1

Dynamic Contrast(DCR) > 10,000:1

Response Time (Gray To Gray) 8ms

Frame Rate 60Hz

Viewing Angle (H / V) 178°/178°

Backlight Type Direct LED

Service Life > 30,000 Hours

Installation Landscape

TOUCH Detection Method Infrared

Avalilable Touch Point 32 Point

Response Time (Type) <= 10 ms

Minimum Response Size >= Φ3mm

Touch Resolution 32768 x 32768

Communication Interface USB

CONNECTIVITY HDMI2.0 Input(s) 2(2Side)

HDMI Output N/A

VGA Input(s) (with Mini Jack Audio Input) 1(Bottom/DE-15F)

DisplayPort 1.2Input(s) N/A

Digital Output(s) 1(Bottom/Coaxial)

Audio/Line In 1(Bottom/Mini Jack)

Line Out 1(Bottom/Mini Jack)

USB 2.0 Port(s) 3(2Front/Type-A, 1Side/Type-A)

USB Type-C 1(Front USB 2.0/Type-C)

Media Card Reader 1(Side/Micro SD)

RS-232C Port(s) 1(Bottom/DE-9F)

LAN Port(s) 1(Side ; RJ45 for 10/100 BaseT)

WI-Fi Module IEEE 802.11 a/b/g/n/ac

Touch Out 1(Side/USB Type-B)

Bluetooth Version 5.0

SOUND Audio Power Output (RMS) 15W x 2

Subwoofer N/A

Speaker Position Down Firing

Sound Mode Standard/News/Music/Movie/Sports/User

SMART SYSTEM CPU ARM Cortex A55x4

GPU Mali-G52

Operating System Android 9.0

Memory 3 GB

On-Board Storage 32 GB

OSD OSD Language Function English, Traditional Chinese

MECHANICAL Dimension of Product (W x H x D) 1959.1*85*1149.8mm

Dimension of Package Carton (W x H x D) 2107*289*1304mm

VESA Hole Pitch (W x H) 800 x 600mm, M8 Screw

Weight of Product 63.5KG

Weight of Package Carton (Gross) 76.1KG

Container Loads-20 20

Container Loads-40 40

Container Loads-40H 40

Front Glass Tempered Glass (Anti-glare Type)

POWER Power Supply AC 110-240 V 50 / 60Hz

Power Consumption (in Operation) TBD

Power Consumption (in Standby) <= 0.5 W

ECO Sensor Yes

Energy Label Rating N/A

ENVIRONMENTAL Operation Temperature 0 - 40 „ƒ

Storage Temperatu
