EXTREME GEN4 STORAGE PERFORMANCE

A PCIe Gen4 x4 extreme data performance controller delivers phenomenal read, write, and response times that leave standard M.2 SSDs in the dust.

Sequential Read/Write Speed

Up to 7,100/6,800 MB/s

Random Read/Write Speed (4KB)

Up to 1M/1.2M IOPS

HIGH-SPEED GEN4 PCIE X4 NVME 1.4 M.2 INTERFACE

Leveraging PCIe Gen4 NVMe 1.4 technology for maximum bandwidth, the MP600 PRO XT delivers incredible storage performance.

BUILT-IN ALUMINUM HEATSPREADER

Helps disperse heat and reduce throttling, so your SSD maintains sustained high performance.

HIGH-DENSITY 3D TLC NAND

Combines high-speed performance with outstanding endurance up to 3000TB written, ensuring that your drive will last and perform well through many years of use.

M.2 2280 Form Factor

Fits directly into your motherboard.

CORSAIR SSD Toolbox Software

Enables advanced drive

SSD Unformatted Capacity 2TB

SSD Smart Support Yes

Weight 0.066kg

SSD Interface PCIe Gen 4.0 x4

SSD Max Sequential Read CDM Up to 7,100MB/s

SSD Max Sequential Write CDM Up to 6,800MB/s

Max Random Write QD32 IOMeter Up to 1.2M IOPS

Max Random Read QD32 IOMeter Up to 1M IOPS

Form Factor M.2 2280

Dimensions Client

Application Consumer MP600 PRO XT M.2 SSD

Quick Start Guide

Weight 0.066

Warranty 5 Year

NAND Technology 3D TLC NAND

Voltage 3.3V, +/- 5%

Endurance 1400TBW

TBW 1400

MTBF 1,600,000 Hours

DEVSLP PS4: <2mW

Encryption AES 256-bit Encryption

Storage Temperature -40°C to +85°C

SSD Operating Temperature 0°C to +70°C

SSD Shock 1500 G

Storage Humidity 93% RH (40° C)

Operating Humidity 90% RH (40° C)

Vibration 20Hz~80Hz/1.52mm, 80Hz~2000Hz/20G
