Description

Gigabyte P650B 650W ATX PSU Power Supply 80+ Bronze 89% 120mm Fan Mesh Braided Cables Single +12V Rail Japanese Capacitors >100K Hrs MTBF


Features

80 PLUS bronze certified: up to 89% efficiency

100% Japanese Capacitors

120mm Hydraulic Bearing (HYB) Fan

Single +12V rail

Meet ErP LOT6 2013 (< 0.5W at standby mode)

OPP/UVP/OVP/SCP/OCP protection

3 years warranty


Model P650B

Type Intel Form Factor ATX 12V v2.31

PFC Active PFC (>0.9 typical)

Input Voltage 100-240 Vac (full range)

Input Current 9A-4A

Input Frequency 50-60 Hz

Output Capacity 650W

Dimension D150 x W140 x H86 mm

Fan Type 120mm Hydraulic Bearing Fan

Efficiency Up to 85% at typical load

MTBF >100,000 hours

Protection OPP/UVP/OVP/SCP/OCP

Regulatory CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE

Connectors ATX/MB 20+4 Pin x 1

CPU/EPS 4+4 Pin x 1

PCI-e 6+2 Pin x 4 SATA x 6

4 Pin Peripheral x 3

4 Pin Floppy x 1


80 Plus Bronze Certified

80 Plus certified ensures the better power efficiency. Less power waste reduces the heat and fan noise. P650B can be up to 89% efficiency.


Reliable Mesh Braided Cable

P650B provides the best solution for the system builds. The mesh braided cable reduces the clutter and improves the airflow in the case.


100% Japanese Capacitors

All capacitors are high quality Japanese capacitors, to produce the efficient performance and to ensure the longer reliability.


Single +12V Rail

Single +12V rail provides the best power output, stability and compatibility for the hardware. And it is the best design for installation.


120mm Hydraulic Bearing (HYB) Fan

120mm Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.

Specifications
SKU PSG-P650B
Barcode # 4719331550301
Brand Gigabyte
Shipping weight 2.5000kg
Shipping width 0.240m
Shipping height 0.186m
Shipping length 0.250m
Assembled length 1.500m
Assembled height 0.860m
Assembled width 1.400m

Gigabyte P650B 650W ATX PSU Power Supply 80 Bronze 89pct 120mm Fan Mesh Braided Cables Single 12V Rail Japanese Cap 100K Hrs MTBF no AU Power Cord

$89.50
RRP $132.00 save 32%

or 4 payments of $22.38 with Learn more

Sold Out

Product Information

SKU:

PSG-P650B

Brand:

Gigabyte

Barcode #:

4719331550301

Shipping Weigth:

2.5000kg

Warranty:

36
