Gigabyte M30 1TB SSD, M.2 2280, PCI-E 3.0 x4, NVMe 1.3, Sequential Read ~3500 MB/s, Sequential Write ~3000 MB/s

FEATURES:

Form Factor: M.2 2280

Interface: PCI-Express 4.0 x4, NVMe 1.4

Total Capacity: 500GB*

Sequential Read Speed : up to 5,000MB/s**

Sequential Write speed : up to 3,800MB/s**

HMB (Host Memory Buffer) supported

TRIM & S.M.A.R.T supported

Energy-efficient

Warranty: Limited 5-years

SPECIFICATIONS:

Interface

PCI-Express 4.0x4, NVMe 1.4

Form Factor

M.2 2280

Total Capacity

500GB

NAND

3D TLC NAND Flash

Sequential Read speed

Up to 5,000 MB/s

Sequential Write speed

Up to 3,800 MB/s

Dimension

80 x 22 x 2.3 mm

Mean time between failure (MTBF)

1.5 million hours

Power Consumption (Active)

Average : R : 4W / W : 4W

Power Consumption(Idle)(ASPT on)

20mW

Temperature (Operating)

0°C to 70°C

Temperature (Storage)

-40°C to 85°C

Warranty

1. Limited 5-years or 300TBW.

2. Limited warranty based on 5 years or 300TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )

*TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.

3. When the usage of an NVME SSD as indicated by the 'Percentage Used' (SMART ID: 05) in SMART page of 'GIGABYTE SSD toolbox' reaches 100 means out of warranty. (A new unused product will show the number of 0)

Note

Test system configuration: configuration may vary by models, we will choose the latest platform for verification.

Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.

Speeds based on internal testing. Actual performance may vary.

1GB = 1 billion bytes. Actual useable capacity may vary.
