Description

The VC840 HDMI to 3G/HD/SD SDI Converter provides a professional way to exchange high definition signals in real time. The SDI and HDMI signal conversion is 100% digital and guarantees no loss of quality for both the audio and video transmission. The VC840 provides 2 low jitter SDI outputs for dual display. The VC840 is the most dependable way to convert signals with confidence when monitoring in any post or broadcast application.


Converts an HDMI input signal to 3G/HD/SD-SDI formats in real time while avoiding transformation loss for both audio and video signals

Supports additional analog stereo audio and coaxial digital audio

HDMI (Deep Color)

LED indication of power and signal status

Supports an SDI distance of up to 90M (3G-SDI), 150M (HDSDI) or 300M (SD-SDI) of RG6

Supported SDI formats:

SD-SDI (SMPTE 259M, up to 270Mbps)

HD-SDI (SMPTE 292M, 296M, up to 1.485Gbps)

3G-SDI (SMPTE 424M, 425M level A, up to 2.97Gbps)

Video Support:

525i@59.96, 625i@50

720p@50/59.94/60

1080i@50/59.94/60

1080p@23.97/24/25/29.97/30/50/59.94/60

Supports 8 audio channels @ 48kHz rate

Offers 2 low-jitter SDI outputs for dual display

Features automatic detection of 3G/HD/SD-SDI signals

Reclocking SDI signals for cascading and thus longer transmission

Locking power connector for secure communications

Selectable EDID settings and EDID learning mode

Specifications
SKU KVA-VC-840
Barcode # 4719264641725
Brand Aten
Shipping weight 1.1800kg
Shipping width 0.262m
Shipping height 0.162m
Shipping length 0.342m
Assembled length 2.420m
Assembled height 0.620m
Assembled width 1.620m

Aten Professional Converter HDMI to 3G HD SD-SDI Converter

$338.72
RRP $439.00 save 23%

or 4 payments of $84.68 with Learn more

Only 1 Left!

Product Information

SKU:

KVA-VC-840

Brand:

Aten

Barcode #:

4719264641725

Shipping Weigth:

1.1800kg

Warranty:

24
